Dymedix TriplePlay FM3 Airflow Filtration Module - Universal (1.5 mm) (12-40202-0001)

Cevi Med#: CM28035

(No reviews yet)  |  Write a Review
Icon of shipping box.

Delivery by Cevi Med

Learn More
Icon of shipping box.

Price Match Guarantee

Learn More
Icon of shipping box.

Purchase Order

Learn More
Icon of shipping box.

Sales Tax Exemption

Learn More

Check out the deliveries we have made in the U.S.A.

Here is a digital portfolio deliveries and installations done by us across the United States. Select a state to see pictures from clinical offices, hospitals, and medical universities in your area.

How do we load our trucks?

$192.35
MSRP: $220.00
Condition:
New
Availability:
5-7 Business Days
Warranty Information:
1 Year
Shipping:
$10.00
Part Number:
12-40202-0001
Icon of shipping box.

Delivery by Cevi Med

Learn More
Icon of shipping box.

Price Match Guarantee

Learn More
Icon of shipping box.

Purchase Order

Learn More
Icon of shipping box.

Sales Tax Exemption

Learn More

Check out the deliveries we have made in the U.S.A.

Here is a digital portfolio deliveries and installations done by us across the United States. Select a state to see pictures from clinical offices, hospitals, and medical universities in your area.

How do we load our trucks?

About this item

Dymedix TriplePlay FM3 Airflow Filtration Module - Universal (1.5 mm)

      • Incorporates  Active circuitry  (more robust frequency filtering module)
      • In addition to apnea-hypopnea-UARS is able to provide a second output channel of snore data, all from one sensor.
      • compatible with PSG systems other than Embla, Alice 5, Alice 6, and Grael.
      • Use with Dymedix TriplePlay disposable or reusable sensors.
      • More Sensitive temperature and pressure change



Specifications

Product # Physical Size Shipping Dimensions Cable Length Weight Pcs/Pkg
12-40202-0001 2.25 (L), 0.5" (W), 1.5" (H) 6" (L), 6" (W) 60"  2 oz 1/ea



Typical Polygraph Settings

Sensitivity

Low Frequency Filter High Frequency Filter
100 - 300 μV/mm 0.1 Hz 15 Hz



Typical Signal Amplitude

Cable Material

Typical Variation
Gray PVC insulation tinsel wire  1 mV peak to peak

Signal amplitudes vary. Response is dependent on variables including sensor position, strap tension, and polygraph characteristics.



Sensor Technology

Operating Conditions Storage Temperature Operating and Storage Humidity
PVDF sensor, ABS filtration module 40 - 104°F -4 - 140°F 5 - 95% (non-condensing)






1 Year
